Product name |
MJK-U1-312 Ultra HD splicing processor |
|
Input Max. Pixel FPS |
600MHz |
|
Output Max. Pixel FPS |
165MHz |
|
4x4 highest resolution |
7680x4320@60Hz |
|
7x2 highest resolution |
3840x7560@60Hz |
|
2x7 highest resolution |
13440x2160@60Hz |
|
3x5 highest resolution |
9600x3240@30Hz |
|
5x3 highest resolution |
5760x5400@30Hz |
|
2x5 highest resolution |
9600x2160@60Hz |
|
5x2 highest resolution |
3840x5400@60Hz |
|
16x1 highest resolution |
30720x1080@60Hz |
|
1x16 highest resolution |
1920x17280@60Hz |
|
1x5 highest resolution |
9600x1080@60Hz |
|
1x7 highest resolution |
13440x1080@60Hz |
|
Factory default resolution |
3840x2160@60Hz |
|
Support customized arbitrary resolution |
√ |
|
Types of input interface |
4 DP 4 HDMI 1 RJ45 Lan 1 RJ45 Debug port HDCP2.2 |
|
Types of output interface |
3~12 HDMI |
|
Size |
482.6mm*396.8mm*44mm |
|
Weight |
5kg |
|
Power |
100~240V |
|
Warranty |
One year |
